3.4inch 480*480 lcd with MIPI interface
3.4inch LCD normally Black 480xRGBx480 MIPI interfacelcd display module forsmart home
Display brightness:300nits
Product advantages: high brightness lcd display,square type lcd display
LCM Model:R34002-480480MZ-QC
LCD Size:3.4inch
LCD Resolution:480x480
LCD Interface:MIPI
Display view angle:IPS
Touch Screen:With capacitive touch
3.4inch LCD module 480x480 tft lcd display parameters:
|
Item |
Specification |
Unit |
|
LCD screen size |
3.4 |
inch |
|
Display Mode |
Normally Black |
-- |
|
Resolution |
480x(RGB)x480 |
Pixel |
|
Pixel arrangement |
RGB Vertical Stripe |
|
|
Viewing angle |
Full Viewing (IPS) |
- |
|
TP-ModuleOutline |
/ |
|
|
LCM Module Outline |
65.72 (W) ×69.64 (H) ×3.7(T) |
mm |
|
LCD AA |
60.48(W)×60.48（H） |
mm |
|
Display Colors |
16.7M |
colors |
|
Driver IC |
/ |
- |
|
LCD Interface |
2Lane MIPI |
-- |
|
Luminance |
300 |
nits |
|
Backlight Arrangement |
White LED |
-- |
|
Capacitive Touch panel |
Option |
|
|
Touch IC |
GT911 |
-- |
|
Touch point |
Multi-point |
-- |
|
Touch structure |
GG |
-- |
|
Touch Interface |
IIC |
-- |
|
Cover lens |
GLASS |
mm |
|
Surface hardness |
≧6H |
-- |
|
Cover lensColors |
Black |
-- |
|
Weight (LCM/TP+LCM) |
/ |
kg |
|
Operating Temperature |
-20℃~ +70℃ |
Deg.c |
|
Storage Temperature |
-30℃~ +80℃ |
Deg.c |
